99SS
PATENTED
☑ Single Cartridge Seal
☑ Standard DIN/ANSI
☑ Moderately Abrasive Services
☑ Max. Solids by Weight: 10~15%
☑ Require NO Flushing
☑ Single Cartridge Seal
☑ Standard DIN/ANSI
☑ Moderately Abrasive Services
☑ Max. Solids by Weight: 10~15%
☑ Require NO Flushing
Model :
CarLife 99SS Single Mechanical seal
Inheriting the features of the Carlife® 99 single cartridge mechanical seal, Carlife® 99SS is primarily designed for slurry, highly solid contents and highly viscous medium environments.
The CarLife 99SS mechanical seal is specifically designed to resist moderate process solids without the need for a flush. Through an advanced design of anti-clogging construction, the seal is capable of providing uninterrupted operation without hanging up due to impurities or abrasive solids. The innovative sub-cartridge design enables faster maintenance and repair than conventional cartridge seals. Fitting both enlarged bore and tapered bore seal chambers, the CarLife 99SS meets the latest design criteria set by the fluid sealing industry and followed by most main seal manufacturers.
In addition to similar construction and assembly procedure, the CarLife 99SS and MGS series have maximum interchangeability of parts. More shared parts mean simpler maintenance process and inventory management. As a result, our CarLife 99SS customers are able to stock fewer inventory parts and pay much lower maintenance and inventory holding costs. And the more CarLife 99SS products they use, the more benefits they can gain from their cost-effective CarLife 99SS seals.
The CarLife 99SS mechanical seal is specifically designed to resist moderate process solids without the need for a flush. Through an advanced design of anti-clogging construction, the seal is capable of providing uninterrupted operation without hanging up due to impurities or abrasive solids. The innovative sub-cartridge design enables faster maintenance and repair than conventional cartridge seals. Fitting both enlarged bore and tapered bore seal chambers, the CarLife 99SS meets the latest design criteria set by the fluid sealing industry and followed by most main seal manufacturers.
In addition to similar construction and assembly procedure, the CarLife 99SS and MGS series have maximum interchangeability of parts. More shared parts mean simpler maintenance process and inventory management. As a result, our CarLife 99SS customers are able to stock fewer inventory parts and pay much lower maintenance and inventory holding costs. And the more CarLife 99SS products they use, the more benefits they can gain from their cost-effective CarLife 99SS seals.
※ More Customized Sealing Solution. Please feel free to contact us.
Catalog Download
【Operating Capabilities】
- Temperature： -40 ~ 150°C (-40 ~ 302 °F )
- Pressure： Up to 256 psig (18 kg/cm2G)
- Surface Speed： Up to 5000 fpm (25 m/s)
-
Max. Solid by Weight： 10~15%
- Stationary Ring：Silicon Carbide / Tungsten Carbide / Carbon Graphite
- Rotary Ring：Silicon Carbide / Tungsten Carbide
- Metal Parts：316 SS / 304 SS / 316L SS / 316Ti SS / Duplex Stainless / Alloy C-276 / Titanium / Monel®
- Elastomeric O-rings：FKM / AFLAS / NBR / EPDM / TV / FFKM (SceniRAZTM / Chemraz® / Kalrez®)
- Gland Gasket：Glass-Filled PTFE / Non- Asbestos / O-Ring
- Springs：316 SS / Alloy C-276 / Inconel®
- Patented disposable sub-cartridge design for ease of maintenance and replacement.
- Separable gland with U-notches for alignment can be used repeatedly.
- Self-aligning compensates for shaft runout up to ±0.5 mm, increasing operational reliability.
- No need for an external flush and associated piping.
- Heavy-duty balanced construction.
- Inner springs are non-rotating and isolated from the process medium during operation.
- Protective hood under springs prevents them from hanging up due to invading solids.
- Jumbo coil spring design provides high fatigue resistance.
- All applied O-rings are micro-polished to ensure smooth and non-sticking surfaces.
- In-line monolithic seal faces with enhanced performance.
- The CarLife® 99SS series shares many parts with the MGS® series.
- For slurry, highly solid contents and highly viscous medium environments
- Ability to tolerate short intermittent dry-running in batch charging and discharging equipment.
- Ideal for crystallizing, medium-viscosity and mediumabrasion media, such as aluminum oxide, slurry, coal, gypsum, sand, phosphate, potassium carbonate, fiber, and syrup.
- Well suited for metal processing and coating, such as titanium, zinc, nickel, copper foil and silver.
- Suitable for a wide range of rotating equipment, such as seawater pumps, wastewater pumps, chemical process pumps, centrifugal pumps, and eccentric screw pumps.
- Widely used in the alcohol (e.g. methanol and ethanol), bio-diesel and corn processing industries.
- Capable of handling processes involving acids, alkalis, corrosive fluids, and vacuum pressure.
- Widely used in the geothermal energy prospecting, rubber, mining, refining, petrochemical, chemical, pulp and paper, metal processing and coating, food and beverage, pharmaceutical, pipeline transportation, electric power, steel, biotechnology, renewable energy, water resource, and wastewater treatment industries.
